Hawkvine HV-VC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H.265, H.264

Product Categories

Beijing RYLink Technology Co., Ltd.

Contact Now

Hawkvine HV-VC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H.265, H.264

Name: Hawkvine HVVC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H265 H264
Brand: HAWKVINE
Price: 100 USD

Brand Name : HAWKVINE

Model Number : HV-VC037

Certification : TS16949

Place of Origin : CHINA

MOQ : 10PCS

Price : 100-10000

Payment Terms : L/C, T/T

Supply Ability : 1000 Per month

Delivery Time : 15days

Packaging Details : Carton Packing

Optical Zoom : 20x

Video Compression : H.265, H.264

Net Weight : 0.83KG

Dimension : 170mm x 80mm x 70mm

Contact Now

Hawkvine HV-VC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H.265, H.264.

HV-VC037 Features:

H.265 video compression, dual stream;
2.14MP, 1/2.8″ CMOS;
Support various HD video formats;
Has 3G-SDI output interface;
20x optical zoom, 12x digital zoom;
With OSD menu;
With RS485 & RS232 control interfaces;

Has image flip function.

Hawkvine No.	HV-VC037
Tracking Camera
Image Sensor	1/2.8″ Exmor CMOS, 2.14MP
HD Signal Format	1080p/60, 1080p/50, 1080p/30, 1080p/25, 1080i/60, 1080i/50, 720p/60, 720p/50, 720p/30, 720p/25
Focal	f=4.7 – 94.0mm
Iris	F=1.6 – F3.5
Optical Zoom	20X
Digital Zoom	12X
Min. Illumination	0.5Lux(Color), 0.1Lux(B/W)
WDR	Yes
Field of View	59.5° – 2.9°
Focus	Auto, Manual, One Push
Shutter Speed	1/1 ~ 1/10.000s
AGC	Auto/Manual
White Balance	Auto, Indoor, Outdoor, One Push, Manual, Auto Track
AE Control	Auto, Manual, Shutter Priority, Iris Priority
BLC	Yes
Noise Reduction	2D/3D
Preset Number	256
OSD	Yes
Image Flip	Yes
S/N Ratio	≥50dB
Network
Max. Image Size	1920 × 1080, @60fps
Video Compression	H.265, H.264
Audio Compression	AAC
Protocol	HTTP, RTP, TCP, UDP, ONVIF, RTSP, RTMP
Simultaneous Users	Up to 10 users
Dual Stream	Support
Interface
Ethernet	RJ45 connector, 100M
Video Output	3G-SDI
Control Interface	RS485, RS232
General
Control Protocol	VISCA, PELCO-D, PELCO-P
Address	1~7(VISCA), 0~255(PELCO-D / PELCO-P)
Power	DC12V
Power Consumption	<15W
Working Temp	0°C ~ +40°C
Storage Temp	-20°C ~ +60°C
Dimension	170mm x 80mm x 70mm
Weight	0.83KG
Body Colour	Grey

Hawkvine HV-VC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H.265, H.264

Hawkvine HV-VC037 IP SDI Integrated Video Conference Camera 20x Optical Zoom H.265, H.264 Images
